Inductive high voltage electroscope product use
The high-voltage electroscope is provided as an inspection of energized cables, inspection of soft cables, inspection of grounding equipment, inspection of neon lamps, tracking of energized wires, inspection of high-frequency radiation, and detection of residual or imported voltages.
Functions and characteristics of inductive high voltage electroscope：
◇The high-voltage electroscope consists of eight voltage gears: 240V, 2KV, 6KV, 11KV, 22KV, 33KV, 132KV, 275KV/AC.
◇High-brightness LED visual warning light.
◇High decibel buzzer warning can prevent noisy construction site environments.
◇The high-voltage electroscope has a self-testing function design.
◇The high-voltage electroscope has a high-strength nylon shell, which is fireproof and shockproof
◇Can detect the voltage of any system.
◇The high-voltage electroscope can be used at a height with the help of an insulated telescopic rod
◇Simple and convenient to use, high efficiency, can be used both indoors and outdoors
◇Obtained the U.S.**number: USD474,705S.Taiwan**Number: No. 207117, new style**No. 085377.
◇Meet the following standards: EN61000-3-2, EN61000-3-3, EN61326-1, EN55011, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-11
The standard configuration of the high-voltage electroscope does not contain an insulating rod
Optional insulation rods: 1 set of HS-120 (1.8meters×3+1.2 meters), or 1 set of HS-120A (1.2 meters)
The actual starting voltage of the instrument (reaching the sound and light indication)：
The closer the distance, the lower the starting voltage.The farther the distance, the higher the starting voltage.The distance in the table is based on 10cm.
